01
Bobbin Winder
Built-in bobbin winding helps keep production moving, so you can prepare bobbins quickly and reduce interruptions during embroidery.
Fast speed
Our most POPULAR Compact Single-Head Embroidery Machine.
Industrial
SINGLE HEAD EMBROIDERY MACHINE
HCD3E-1501 (Elite Pro)
Preferred model
Request demo
Available on request
Starting from:
£7,995.00 + VAT
HCD3E-1501-40 Tech Specs
Ideal for professional embroidery businesses, high-output studios, and commercial users who need a more robust single-head machine, the HCD3E-1501-40 is designed for those who want full-industrial construction, dependable performance, and the versatility to handle a wide range of materials and finished goods. It is especially well suited for caps, garments, commercial embroidery work, and demanding production environments.
Embroidery Machine
HCD3E-1501
- Heads
- Single
- Needles / Colours:
- 15
- Embroidery Area:
- 400 × 520 mm
- Cap Frame:
- 70 × 180 mm
- Wide Cap Frame:
- 80 × 360 mm
- Dimensions:
- 845 × 778 × 871 mm
- Weight:
- 106 kg
- Power Consumption
- 240 W
- Frequency:
- 50/60 Hz
- Power Supply:
- Single Phase 100–115V / 200–230V
- Fonts:
- 12 built-in fonts / 6 sizes
- Built-in Designs:
- 40 million stitches & 999 patterns
- Max Speed (Tubular):
- 1,200 s.p.m.
- Max Speed (Cap):
- 1000 s.p.m.
- LCD Touch Screen:
- 10.4" color LCD touch screen control panel
- USB & Mouse Support:
- Included
- Machine Monitoring
- Included
- Direct PC Connection
- Included
- Cross-Type Laser Position Marker:
- Included
- One-Point Frames:
- Optional extra
- Built-in Bobbin Thread Winder:
- Included
- Barcode Reader Interface:
- Included
- Laser Position Marker:
- Optional extra
- Auto Angle Adjustment:
- Included
Explore Our
Machine Features
02
LED Work Light
A bright built-in LED light illuminates the work area clearly, helping improve visibility and precision.
03
Repositionable Arms
Designed for added flexibility, the repositionable arms allow the machine to use the same hoops as the standard-field HCD3E-1501, making it suitable for shirts, jackets, hoodies, beanies and more.
04
PC Connection : LAN/USB
Direct PC connection via LAN or USB makes it easy to transfer designs and integrate the machine into your existing workflow, whether used individually or across a network.
05
Pattern Transfer with HAPPY LINK/LAN
Included PC communication software helps you edit and transfer embroidery patterns efficiently, with HAPPY LINK/LAN supporting a more connected production setup.
06
LCD Touch Screen Controller
The extra-large 400 × 1,200 mm sewing area, gives you more room to handle larger formats, bags and other oversized embroidery applications with ease.
Ideal for start-ups
Compare our models
Single-Headed embroidery machines
Midwest is the perfect partner to help you start and grow your embroidery business — whether you're new to the industry or ready to scale your operation.
HCD3E-1501
- Needles:
- Single
- Speed:
- 1,200 s.p.m.
- Area:
- 400 × 520 mm
- Price:
- £7,995.00
All our machines can be used individually or network together. Happy LAN software is supplied FREE OF CHARGE
Enjoy a smooth start with expert installation and software setup included.
